| Basic Information | |||
| Usage | Delivery Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 12000mm | ||
| Width | 2550mm | ||
| Height | 3830mm | ||
| Curb Weight | 9700kg | ||
| Gross Weight | 15900kg | ||
| Seats | 3 | ||
| Max Speed | 109km/h | ||
| Chassis | |||
| Chassis Model | CA5160XXYP62K1L7E5 | ||
| Front/Rear Overhang | 1400/3500mm | ||
| Number of Leaf Springs | 7/7+6,3/- | ||
| Number of Axles | 2 | ||
| Wheelbase | 7100mm | ||
| Axle Load | 5600/10300kg | ||
| Front Wheel Track | 1800,1855,1950mm | ||
| Rear Wheel Track | 1800,1878mm | ||
| Approaching/Departuring Angle | 18/8° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 10R22.5 16PR ,9.00R20 16PR, 275/70R22.5 16PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| CA4DK1-22E5 | China FAW Group Corporation | 165kW | 4764ml |
| CA4DK1-22E51 | China FAW Group Corporation | 165kW | 4764ml |
| CA6DH1-25E51 | China FAW Group Corporation | 186kW | 5700ml |
