| Basic Information | |||
| Usage | Delivery Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 7100,6950mm | ||
| Width | 2200mm | ||
| Height | 3400mm | ||
| Curb Weight | 5770kg | ||
| Gross Weight | 11495kg | ||
| Seats | 2，3 | ||
| Max Speed | 90km/h | ||
| Chassis | |||
| Chassis Model | EQ1111GLJ | ||
| Front/Rear Overhang | 1250/2050mm | ||
| Number of Leaf Springs | 8/11+8,8/10+7,11/9+7,9/10+8 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3650,3800,3950,4200,4500mm | ||
| Axle Load | 4825/6670kg | ||
| Front Wheel Track | 1760,1810,1910mm | ||
| Rear Wheel Track | 1670,1690,1800,1586,1650mm | ||
| Approaching/Departuring Angle | 22/14° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 8.25-20 16PR,8.25R20 16PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| CY4BK151 | Dongfeng Chaoyang Diesel Co., Ltd. | 105kW | 3856ml |
| 4DX23-140E5 | FAW Jiefang Automobile Co., Ltd. Wuxi Diesel Plant | 105kW | 3857ml |
| CY4SK251 | Dongfeng Chaoyang Diesel Co., Ltd. | 115kW | 3856ml |
| YC4S150-50 | Guangxi Yuchai Machinery Co., Ltd. | 110kW | 3767ml |
