| Basic Information |
| Usage |
Vehicle for Special Work |
| Fuel Type |
Diesel |
| Emission Standard |
GB17691-2005 national Ⅴ emission standards, GB3847-2005 |
| Length |
11990mm |
| Width |
2500mm |
| Height |
3720mm |
| Curb Weight |
14400kg |
| Gross Weight |
31000kg |
| Seats |
2,3 |
| Max Speed |
89km/h |
| Chassis |
| Chassis Model |
SX1310FB |
| Front/Rear Overhang |
1525/2390,1525/2590,1525/2690,1525/3290mm |
| Number of Leaf Springs |
13/13/12,4/4/5,5/5/5,4/4/12,5/5/12,左14右13/左14右13/12 |
| Number of Axles |
4 |
| Wheelbase |
1800+3575+1400,1950+3425+1400,1800+4575+1400,1950+4425+1400,1800+2975+1400,1800+3975+1400,2100+4375+1400,2100+4575+1400,1800+3775+1400mm |
| Axle Load |
6500/6500/18000(two axles)kg |
| Front Wheel Track |
2036/2036mm |
| Rear Wheel Track |
1860/1860mm |
| Approaching/Departuring Angle |
18/12° |
| Tire |
| Number of Tires |
12 |
| Tire |
11.00-20 18PR,11.00R20 18PR,12.00-20 18PR,12.00R20 16PR,12.00R20 18PR |
| Engine |
| Model |
WP10.310E53,WP10.290E53,WP10.336E55,WP7.300E55,WP10.336E53,WP9H336E50,WP12.375E50,ISM11E5 385,WP10H375E50,WP10H400E50 |
| Power |
228,213,247,220,247,247,276,280,276,294kW |
| Brand |
Weichai Power Co., Ltd.;Weichai Power Co., Ltd.;Weichai Power Co., Ltd.;Weichai Power Co., Ltd.;Weichai Power Co., Ltd.;Weichai Power Co., Ltd.;Weichai Power Co., Ltd.;Xi'an Cummins Engine Co., Ltd.;Weichai Power Co., Ltd.;Weichai Power Co., Ltd. |
| Displacement |
9726,9726,9726,7470,9726,8800,11596,10800,9500,9500ml |
