| Basic Information |
| Usage |
Vehicle for Special Work |
| Fuel Type |
Diesel |
| Emission Standard |
GB17691-2005 national Ⅴ emission standards, GB3847-2005 |
| Length |
8300mm |
| Width |
2500mm |
| Height |
3820mm |
| Curb Weight |
9510kg |
| Gross Weight |
16000kg |
| Seats |
3 |
| Max Speed |
90km/h |
| Chassis |
| Chassis Model |
EQ1161LJ9BDE |
| Front/Rear Overhang |
1230/2370,1230/2570mm |
| Number of Leaf Springs |
8/10+7 |
| Number of Axles |
2 |
| Wheelbase |
3950,4500,4700,5200,5600mm |
| Axle Load |
5600/10400kg |
| Front Wheel Track |
1858,1949,1923,1891mm |
| Rear Wheel Track |
1806,1865mm |
| Approaching/Departuring Angle |
19/11° |
| Tire |
| Number of Tires |
6 |
| Tire |
9.00R20,10.00R20 |
| Engine |
| Model |
YC4EG170-50,YC4EG185-50,ISB210 50,ISB180 50,ISD160 50,YC4S160-50,YC6JA180-50 |
| Power |
125,136,155,132,118,118,132kW |
| Brand |
Guangxi Yuchai Machinery Co., Ltd.;Guangxi Yuchai Machinery Co., Ltd.;Dongfeng Cummins Engine Co., Ltd.;Dongfeng Cummins Engine Co., Ltd.;Dongfeng Cummins Engine Co., Ltd.;Guangxi Yuchai Machinery Co., Ltd.;Guangxi Yuchai Machinery Co., Ltd. |
| Displacement |
4730,4730,5900,5900,4500,3767,6870ml |
