| Basic Information | |||
| Usage | Medical Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB3847-2005,GB17691-2005 national Ⅳ emission standards | ||
| Length | 8045mm | ||
| Width | 2480mm | ||
| Height | 3256,3356,3440,3466mm | ||
| Curb Weight | 8360kg | ||
| Gross Weight | 10600kg | ||
| Seats | 4-9 | ||
| Max Speed | 115km/h | ||
| Chassis | |||
| Chassis Model | XMQ6780R3 | ||
| Front/Rear Overhang | 1775/2420mm | ||
| Number of Leaf Springs | 3/4,6/9,-/- | ||
| Number of Axles | 2 | ||
| Wheelbase | 3850mm | ||
| Axle Load | 3150/7450kg | ||
| Front Wheel Track | 1900,1930,2034,2074mm | ||
| Rear Wheel Track | 1800,1840mm | ||
| Approaching/Departuring Angle | 10/8° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 9R22.5,8R22.5,255/70R22.5 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| YC4G200-40 | Guangxi Yuchai Machinery Co., Ltd. | 147kW | 5200ml |
| YC4G180-40 | Guangxi Yuchai Machinery Co., Ltd. | 132kW | 5200ml |
| WP5.180E40 | Weichai Power Co., Ltd. | 132kW | 4760ml |
| WP5.200E40 | Weichai Power Co., Ltd. | 147kW | 4760ml |
