| Basic Information | |||
| Usage | Medical Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB3847-2005,GB17691-2005 national Ⅳ emission standards | ||
| Length | 11480mm | ||
| Width | 2540mm | ||
| Height | 3580,3690mm | ||
| Curb Weight | 11700kg | ||
| Gross Weight | 16200kg | ||
| Seats | 4-20 | ||
| Max Speed | 120km/h | ||
| Chassis | |||
| Chassis Model | XMQ6110R7 | ||
| Front/Rear Overhang | 2390/3290mm | ||
| Number of Leaf Springs | 10/12,-/- | ||
| Number of Axles | 2 | ||
| Wheelbase | 5800mm | ||
| Axle Load | 5400/10800kg | ||
| Front Wheel Track | 2020,2080,2086mm | ||
| Rear Wheel Track | 1860,1850mm | ||
| Approaching/Departuring Angle | 10/9° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 295/80R22.5 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| YC6L280-42 | Guangxi Yuchai Machinery Co., Ltd. | 206kW | 8424ml |
| YC6L310-42 | Guangxi Yuchai Machinery Co., Ltd. | 228kW | 8424ml |
| P11C-VD | Shanghai Hino Engine Co., Ltd. | 240kW | 10520ml |
| YC6G300-40 | Guangxi Yuchai Machinery Co., Ltd. | 221kW | 7800ml |
