| Basic Information | |||
| Usage | Medical Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2018 national Ⅵ emission standards | ||
| Length | 12000mm | ||
| Width | 2550mm | ||
| Height | 3740,3810,3880,3960mm | ||
| Curb Weight | 14000kg | ||
| Gross Weight | 18000kg | ||
| Seats | 2-9 | ||
| Max Speed | 100km/h | ||
| Chassis | |||
| Chassis Model | XMQ6121RD6 | ||
| Front/Rear Overhang | 2600/3400mm | ||
| Number of Leaf Springs | 10/12,-/- | ||
| Number of Axles | 2 | ||
| Wheelbase | 6000mm | ||
| Axle Load | 6500/11500kg | ||
| Front Wheel Track | 2030,2045,2085mm | ||
| Rear Wheel Track | 1870,1890mm | ||
| Approaching/Departuring Angle | 9/9° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 295/80R22.5 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| YCK08330-60 | Guangxi Yuchai Machinery Co., Ltd. | 243kW | 7698ml |
