| Basic Information | |||
| Usage | Medical Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 8945mm | ||
| Width | 2480mm | ||
| Height | 3282,3382,3512,3600,3332,3447,3556mm | ||
| Curb Weight | 9895kg | ||
| Gross Weight | 12000kg | ||
| Seats | 2-9 | ||
| Max Speed | 100km/h | ||
| Chassis | |||
| Chassis Model | XMQ6870R6 | ||
| Front/Rear Overhang | 1885/2760mm | ||
| Number of Leaf Springs | 3/3,4/4,7/9,7/10,8/11,-/- | ||
| Number of Axles | 2 | ||
| Wheelbase | 4300mm | ||
| Axle Load | 4000/8000kg | ||
| Front Wheel Track | 2058,2079,2027mm | ||
| Rear Wheel Track | 1860,1880mm | ||
| Approaching/Departuring Angle | 10/8° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 9R22.5 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| YC6J220-50 | Guangxi Yuchai Machinery Co., Ltd. | 162kW | 6500ml |
| YC6J245-50 | Guangxi Yuchai Machinery Co., Ltd. | 180kW | 6500ml |
| WP6.245E50 | Weichai (Weifang) Medium-duty Diesel Co., Ltd. | 180kW | 6750ml |
