| Basic Information | |||
| Usage | Medical Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 10990mm | ||
| Width | 2500mm | ||
| Height | 3580,3440,3700,3640mm | ||
| Curb Weight | 13000kg | ||
| Gross Weight | 16400kg | ||
| Seats | 2-9 | ||
| Max Speed | 100km/h | ||
| Chassis | |||
| Chassis Model | XMQ6112AYD5D | ||
| Front/Rear Overhang | 2200/3150mm | ||
| Number of Leaf Springs | 9/11,10/12,11/13,-/- | ||
| Number of Axles | 2 | ||
| Wheelbase | 5640mm | ||
| Axle Load | 5500/10900kg | ||
| Front Wheel Track | 2054,2072mm | ||
| Rear Wheel Track | 1860,1880mm | ||
| Approaching/Departuring Angle | 9.5/9° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 11R22.5 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| YC6L260-50 | Guangxi Yuchai Machinery Co., Ltd. | 191kW | 8424ml |
