| Basic Information | |||
| Usage | Medical Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2018 national Ⅵ emission standards | ||
| Length | 6995,7000mm | ||
| Width | 2090mm | ||
| Height | 2730,2785,2840,2985mm | ||
| Curb Weight | 5050kg | ||
| Gross Weight | 7030kg | ||
| Seats | 2-9 | ||
| Max Speed | 100km/h | ||
| Chassis | |||
| Chassis Model | XMQ6706DYD6D | ||
| Front/Rear Overhang | 1135/1925,1135/1930mm | ||
| Number of Leaf Springs | 3/4 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3935mm | ||
| Axle Load | 2530/4500kg | ||
| Front Wheel Track | 1700mm | ||
| Rear Wheel Track | 1560,1525mm | ||
| Approaching/Departuring Angle | 19/12° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 215/75R17.5 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| YCY30150-60A | Guangxi Yuchai Machinery Co., Ltd. | 110kW | 2970ml |
