| Basic Information | |||
| Usage | Medical Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2018 national Ⅵ emission standards | ||
| Length | 5995mm | ||
| Width | 2090mm | ||
| Height | 2730,2785,2840,2985mm | ||
| Curb Weight | 3830kg | ||
| Gross Weight | 4495kg | ||
| Seats | 2-4 | ||
| Max Speed | 100km/h | ||
| Chassis | |||
| Chassis Model | XMQ6606DYD6D | ||
| Front/Rear Overhang | 1140/1555mm | ||
| Number of Leaf Springs | 3/3 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3300mm | ||
| Axle Load | 2100/2395kg | ||
| Front Wheel Track | 1700mm | ||
| Rear Wheel Track | 1560,1525mm | ||
| Approaching/Departuring Angle | 19/14° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 215/75R17.5 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| YCY24140-60A | Guangxi Yuchai Machinery Co., Ltd. | 103kW | 2360ml |
