| Basic Information | |||
| Usage | Medical Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2018 national Ⅵ emission standards | ||
| Length | 8210mm | ||
| Width | 2500mm | ||
| Height | 3275,3340,3400,3450,3520,3590mm | ||
| Curb Weight | 9135kg | ||
| Gross Weight | 12520kg | ||
| Seats | 2-9 | ||
| Max Speed | 100km/h | ||
| Chassis | |||
| Chassis Model | XMQ6801RD6 | ||
| Front/Rear Overhang | 1870/2490mm | ||
| Number of Leaf Springs | -/-,7/11,7/10,6/10 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3850mm | ||
| Axle Load | 4070/8450kg | ||
| Front Wheel Track | 2037,2076mm | ||
| Rear Wheel Track | 1873mm | ||
| Approaching/Departuring Angle | 11/9° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 9R22.5 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| YCK05230-60 | Guangxi Yuchai Machinery Co., Ltd. | 169kW | 5132ml |
| WP4.6NQ220E61 | Weichai Power Co., Ltd. | 162kW | 4580ml |
