| Basic Information | |||
| Usage | Recreational Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 13700mm | ||
| Width | 2550mm | ||
| Height | 3910,3980mm | ||
| Curb Weight | 18000kg | ||
| Gross Weight | 21700kg | ||
| Seats | 2-9 | ||
| Max Speed | 100km/h | ||
| Chassis | |||
| Chassis Model | XMQ6136RD5 | ||
| Front/Rear Overhang | 2600/3100mm | ||
| Number of Leaf Springs | -/-/- | ||
| Number of Axles | 3 | ||
| Wheelbase | 6500+1500mm | ||
| Axle Load | 6750/14950(two axles)kg | ||
| Front Wheel Track | 2080mm | ||
| Rear Wheel Track | 1876/2080mm | ||
| Approaching/Departuring Angle | 8/9° | ||
| Tire | |||
| Number of Tires | 8 | ||
| Tire | 295/80R22.5 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| WP12.400E50 | Weichai Power Co., Ltd. | 294kW | 11596ml |
