| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB3847-2005,GB17691-2005 national Ⅳ emission standards | ||
| Length | 7000mm | ||
| Width | 2050mm | ||
| Height | 2640,2780mm | ||
| Curb Weight | 4250kg | ||
| Gross Weight | 6400kg | ||
| Max Speed | 100km/h | ||
| Chassis | |||
| Chassis Model | XMQ6706AYD4D | ||
| Front/Rear Overhang | 1135/1930mm | ||
| Number of Leaf Springs | 3/3,3/4,-/3 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3935mm | ||
| Axle Load | 2270/4130kg | ||
| Front Wheel Track | 1690,1690,1665mm | ||
| Rear Wheel Track | 1490,1525,1525mm | ||
| Approaching/Departuring Angle | 18/7° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 7.00R16,7.00-16,215/75R17.5 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| YC4FA130-40 | Guangxi Yuchai Machinery Co., Ltd. | 95kW | 2982ml |
| SOFIM8140.43S4 | NAVECO Ltd. | 95kW | 2798ml |
| JE4D28A | Jiangxi Woerfu Engine Co., Ltd. | 103kW | 2776ml |
