| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 6630mm | ||
| Width | 2270mm | ||
| Height | 2750,2890,2910,3050,2850,2970mm | ||
| Curb Weight | 4600kg | ||
| Gross Weight | 6500kg | ||
| Seats | 2-5 | ||
| Max Speed | 100km/h | ||
| Chassis | |||
| Chassis Model | XMQ6570RD5 | ||
| Front/Rear Overhang | 1200/2130mm | ||
| Number of Leaf Springs | 11/10 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3300mm | ||
| Axle Load | 2300/4200kg | ||
| Front Wheel Track | 1830mm | ||
| Rear Wheel Track | 1600mm | ||
| Approaching/Departuring Angle | 18.5/12° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 7.00R16,7.00R16LT | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| WP3.7Q130E50 | Weichai Power Yangzhou Diesel Co., Ltd. | 96kW | 3660ml |
