| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Gasoline | ||
| Emission Standard | GB18352.5-2013 national Ⅴ emission standards | ||
| Length | 5250,5000mm | ||
| Width | 1900mm | ||
| Height | 2600mm | ||
| Curb Weight | 2740kg | ||
| Gross Weight | 3365kg | ||
| Seats | 2 | ||
| Max Speed | 95km/h | ||
| Chassis | |||
| Chassis Model | KMC1035Q32D5 | ||
| Front/Rear Overhang | 555/1505,555/1455mm | ||
| Number of Leaf Springs | 6/7+4 | ||
| Number of Axles | 2 | ||
| Wheelbase | 2990,3190mm | ||
| Axle Load | 1210/2155kg | ||
| Front Wheel Track | 1410mm | ||
| Rear Wheel Track | 1380,1335,1440mm | ||
| Approaching/Departuring Angle | 32/14,32/15° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 6.00-14LT 8PR,185R14LT 6PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| LJ469Q-1AEB | Liuzhou Wuling Liuji Power Co., Ltd. | 64kW | 1249ml |
| LJ4A15Q | Liuzhou Wuling Liuji Power Co., Ltd. | 79.5kW | 1499ml |
