| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Gasoline | ||
| Emission Standard | GB18352.5-2013 national Ⅴ emission standards | ||
| Length | 5120,4820,5165,4865mm | ||
| Width | 1660mm | ||
| Height | 2540,2380mm | ||
| Curb Weight | 2620kg | ||
| Gross Weight | 3240kg | ||
| Seats | 2 | ||
| Max Speed | 90km/h | ||
| Chassis | |||
| Chassis Model | KMC1033Q28D5 | ||
| Front/Rear Overhang | 900/1420,900/1360,945/1420,945/1360mm | ||
| Number of Leaf Springs | 5/5 | ||
| Number of Axles | 2 | ||
| Wheelbase | 2800,2560mm | ||
| Axle Load | 1170/2070kg | ||
| Front Wheel Track | 1290mm | ||
| Rear Wheel Track | 1210mm | ||
| Approaching/Departuring Angle | 35/23,35/25,25/23,25/25° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 175R14LT,6.00-13LT | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| LJ469Q-1AEB | Liuzhou Wuling Liuji Power Co., Ltd. | 64kW | 1249ml |
