| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Hybrid power | ||
| Emission Standard | GB18352.5-2013 national Ⅴ emission standards | ||
| Length | 5110,5360mm | ||
| Width | 1840mm | ||
| Height | 2660mm | ||
| Curb Weight | 2370kg | ||
| Gross Weight | 3495kg | ||
| Seats | 2 | ||
| Max Speed | 95km/h | ||
| Chassis | |||
| Chassis Model | KMC1036L26D5 | ||
| Front/Rear Overhang | 1120/1390,1120/1440mm | ||
| Number of Leaf Springs | 9/8+4 | ||
| Number of Axles | 2 | ||
| Wheelbase | 2600,2800mm | ||
| Axle Load | 1260/2235kg | ||
| Front Wheel Track | 1390,1368mm | ||
| Rear Wheel Track | 1375,1335mm | ||
| Approaching/Departuring Angle | 17/18° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 6.00-14LT 8PR,185R14LT 6PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| LJ469Q-1AEB | Liuzhou Wuling Liuji Power Co., Ltd. | 64/54kW | 1249ml |
| LJ4A15Q | Liuzhou Wuling Liuji Power Co., Ltd. | 79.5/69kW | 1499ml |
