| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Gasoline | ||
| Emission Standard | GB18352.5-2013 national Ⅴ emission standards | ||
| Length | 4310,4700,4970mm | ||
| Width | 1760mm | ||
| Height | 2650,2450mm | ||
| Curb Weight | 1200kg | ||
| Gross Weight | 2280kg | ||
| Seats | 2 | ||
| Max Speed | 90km/h | ||
| Chassis | |||
| Chassis Model | KMC1021Q29D5 | ||
| Front/Rear Overhang | 560/1205,560/1240,560/1360mm | ||
| Number of Leaf Springs | -/6 | ||
| Number of Axles | 2 | ||
| Wheelbase | 2545,2900,3050mm | ||
| Axle Load | 970/1310kg | ||
| Front Wheel Track | 1425mm | ||
| Rear Wheel Track | 1420mm | ||
| Approaching/Departuring Angle | 30/20,30/19,30/18° | ||
| Tire | |||
| Number of Tires | 4 | ||
| Tire | 165R14LT 8PR,175R14LT 6PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| LJ469Q-1AEB | Liuzhou Wuling Liuji Power Co., Ltd. | 64kW | 1249ml |
