| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 5440,5930,5995mm | ||
| Width | 1940,1990mm | ||
| Height | 2940,3000mm | ||
| Curb Weight | 3870kg | ||
| Gross Weight | 4495kg | ||
| Seats | 2 | ||
| Max Speed | 95km/h | ||
| Chassis | |||
| Chassis Model | KMC1041A28D5 | ||
| Front/Rear Overhang | 1130/1510,1130/1700,1130/1565mm | ||
| Number of Leaf Springs | 9/8+4,3/5+3 | ||
| Number of Axles | 2 | ||
| Wheelbase | 2800,3100,3300mm | ||
| Axle Load | 1610/2885kg | ||
| Front Wheel Track | 1495mm | ||
| Rear Wheel Track | 1490mm | ||
| Approaching/Departuring Angle | 20/18,20/16° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 6.50-16LT 10PR,6.50R16LT 10PR,7.00-16LT 8PR,7.00R16LT 8PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| WP2.1Q82E50 | Weichai Power Yangzhou Diesel Co., Ltd. | 60kW | 2088ml |
| D19TCIE1 | Kunming Yunnei Power Co., Ltd. | 75kW | 1910ml |
| YN27CRE1 | Kunming Yunnei Power Co., Ltd. | 70kW | 2672ml |
| SD4D25R-70 | Jiangsu Sida Power Machinery Co., Ltd. | 70kW | 2545ml |
| 4DW93-84E5 | FAW Jiefang Automobile Co., Ltd. Wuxi Diesel Plant | 64kW | 2540ml |
| YCD4N4S-110 | Guangxi Yuchai Power Machinery Co., Ltd. | 80kW | 2799ml |
| WP2.3Q110E50 | Weichai Power Yangzhou Diesel Co., Ltd. | 81kW | 2290ml |
| CA4DB1-11E5 | FAW Jiefang Automobile Co., Ltd. Wuxi Diesel Plant | 80kW | 2200ml |
