| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 5390,5080mm | ||
| Width | 1770,1850mm | ||
| Height | 2700mm | ||
| Curb Weight | 3590kg | ||
| Gross Weight | 4405kg | ||
| Seats | 2+3 | ||
| Max Speed | 95km/h | ||
| Chassis | |||
| Chassis Model | KMC1040A26S5 | ||
| Front/Rear Overhang | 1060/1530,1060/1420,1100/1490,1100/1380mm | ||
| Number of Leaf Springs | 9/8+4,3/5+3 | ||
| Number of Axles | 2 | ||
| Wheelbase | 2600,2800mm | ||
| Axle Load | 1585/2820kg | ||
| Front Wheel Track | 1395,1420mm | ||
| Rear Wheel Track | 1340,1375mm | ||
| Approaching/Departuring Angle | 18/17,18/16,17/17,17/18° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 6.00-14LT,6.00-15LT | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| WP2.1Q82E50 | Weichai Power Yangzhou Diesel Co., Ltd. | 60kW | 2088ml |
| D19TCIE1 | Kunming Yunnei Power Co., Ltd. | 75kW | 1910ml |
| SD4D25R-65 | Jiangsu Sida Power Machinery Group Co., Ltd. | 65kW | 2433ml |
| WP2.3Q95E50 | Weichai Power Yangzhou Diesel Co., Ltd. | 70kW | 2290ml |
| YCD4V4S-95 | Guangxi Yuchai Power Machinery Co., Ltd. | 70kW | 2488ml |
