| Basic Information | |||
| Usage | Engineering Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 9800,10200mm | ||
| Width | 2550mm | ||
| Height | 3990,3900mm | ||
| Curb Weight | 14250kg | ||
| Gross Weight | 31000kg | ||
| Seats | 2 | ||
| Max Speed | 80km/h | ||
| Chassis | |||
| Chassis Model | CQ3316HTWG23-276 | ||
| Front/Rear Overhang | 1435/2165,1435/2565mm | ||
| Number of Leaf Springs | 3/3/4,3/3/6,3/3/12,9/9/12 | ||
| Number of Axles | 4 | ||
| Wheelbase | 1800+2330+1400,1800+2700+1400,1800+3000+1400mm | ||
| Axle Load | 6500/6500/18000(two axles)kg | ||
| Front Wheel Track | 2006/2006,2020/2020mm | ||
| Rear Wheel Track | 1850/1850mm | ||
| Approaching/Departuring Angle | 21/14° | ||
| Tire | |||
| Number of Tires | 12 | ||
| Tire | 11.00-20 18PR,11.00R20 18PR,12.00-20 18PR,12.00R20 18PR,315/80R22.5 18PR,12R22.5 18PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| WP10.336E55 | Weichai Power Co., Ltd. | 247kW | 9726ml |
