| Basic Information | |||
| Usage | Fire Extinguishing Truck | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 11470mm | ||
| Width | 2500mm | ||
| Height | 3820mm | ||
| Curb Weight | 19150kg | ||
| Gross Weight | 37600kg | ||
| Seats | 2+4 | ||
| Max Speed | 90km/h | ||
| Chassis | |||
| Chassis Model | Arocs 4158 8X4 | ||
| Front/Rear Overhang | 1550/2520mm | ||
| Number of Leaf Springs | 4/4/4/4 | ||
| Number of Axles | 4 | ||
| Wheelbase | 1750+4300+1350mm | ||
| Axle Load | 5580/6120/12950/12950kg | ||
| Front Wheel Track | 2140/2140,2058/2058mm | ||
| Rear Wheel Track | 1804/1804mm | ||
| Approaching/Departuring Angle | 14/11° | ||
| Tire | |||
| Number of Tires | 12 | ||
| Tire | 385/65R22.5/315/80R22.5,315/80R22.5 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| OM473LA.5-52 | Daimler AG | 430kW | 15569ml |
