| Basic Information | |||
| Usage | Police Van | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 7795,7935mm | ||
| Width | 2220mm | ||
| Height | 3150,3070mm | ||
| Curb Weight | 7420kg | ||
| Gross Weight | 10000kg | ||
| Seats | 3+3,3 | ||
| Max Speed | 110km/h | ||
| Chassis | |||
| Chassis Model | QL1100A8MAY | ||
| Front/Rear Overhang | 1110/2210,1250/2210mm | ||
| Number of Leaf Springs | 8/10+6 | ||
| Number of Axles | 2 | ||
| Wheelbase | 4475mm | ||
| Axle Load | 3350/6650kg | ||
| Front Wheel Track | 1680mm | ||
| Rear Wheel Track | 1650mm | ||
| Approaching/Departuring Angle | 20/16,17/13° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 235/75R17.5 14PR,8.25R20 14PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| 4HK1-TC51 | Qingling Isuzu (Chongqing) Engine Co., Ltd. | 141kW | 5193ml |
| 4HK1-TC50 | Qingling Isuzu (Chongqing) Engine Co., Ltd. | 151kW | 5193ml |
