| Basic Information | |||
| Usage | Semi-Trailer | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2018 national Ⅵ emission standards | ||
| Length | 11900mm | ||
| Width | 2550mm | ||
| Height | 3995,3920mm | ||
| Curb Weight | 18065kg | ||
| Gross Weight | 31000kg | ||
| Seats | 2 | ||
| Max Speed | 90km/h | ||
| Chassis | |||
| Chassis Model | CQ1317HY6Z | ||
| Front/Rear Overhang | 1435/2665mm | ||
| Number of Leaf Springs | 10/10/12,9/9/12 | ||
| Number of Axles | 4 | ||
| Wheelbase | 2000+4400+1400mm | ||
| Axle Load | 6500/6500/18000(two axles)kg | ||
| Front Wheel Track | 2020/2020,2040/2040,2060/2060mm | ||
| Rear Wheel Track | 1858/1858mm | ||
| Approaching/Departuring Angle | 16/9° | ||
| Tire | |||
| Number of Tires | 12 | ||
| Tire | 12R22.5 18PR,295/80R22.5 18PR,315/80R22.5 18PR,12.00R20 18PR,11.00R20 18PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| SC12E460Q6 | Shanghai Diesel Engine Co., Ltd. | 338kW | 11810ml |
| SC12E480Q6 | Shanghai Diesel Engine Co., Ltd. | 353kW | 11810ml |
| SC12E420Q6 | Shanghai Diesel Engine Co., Ltd. | 309kW | 11810ml |
| SC12E440Q6 | Shanghai Diesel Engine Co., Ltd. | 323kW | 11810ml |
| F3GCE611D*M | Saic Fiat Powertrain Hongyan Co., Ltd. | 337kW | 11120ml |
| F3GCE611E*M | Saic Fiat Powertrain Hongyan Co., Ltd. | 317kW | 11120ml |
| F3GCE611F*M | Saic Fiat Powertrain Hongyan Co., Ltd. | 295kW | 11120ml |
