| Basic Information | |||
| Usage | Police Van | ||
| Fuel Type | Electric vehicle | ||
| Length | 4944,4744,5084,4884,5304,5104,5444,5244mm | ||
| Width | 1972mm | ||
| Height | 2040,2080,2240,2280mm | ||
| Curb Weight | 2495kg | ||
| Gross Weight | 3510kg | ||
| Seats | 3+3,3+2,2+3 | ||
| Max Speed | 120km/h | ||
| Chassis | |||
| Chassis Model | JX5040XXYTC-M5BEV | ||
| Front/Rear Overhang | 1026/1083,1026/883,1166/1083,1166/883,1026/1443,1026/1243,1166/1443,1166/1243mm | ||
| Number of Leaf Springs | -/3 | ||
| Number of Axles | 2 | ||
| Wheelbase | 2835mm | ||
| Axle Load | 1480/2030kg | ||
| Front Wheel Track | 1692mm | ||
| Rear Wheel Track | 1700mm | ||
| Approaching/Departuring Angle | 21/21,21/23,17/23,17/21° | ||
| Tire | |||
| Number of Tires | 4 | ||
| Tire | 215/65R16C | ||
| Electrical Machinery | |||
| Model | Brand | Max Power | |
| TZ260XSDA4 | Xiamen Jieou Land & New Energy Co., Ltd. | 120kW | |
