| Basic Information | |||
| Usage | Fire Extinguishing Truck | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 6070mm | ||
| Width | 2050mm | ||
| Height | 3000mm | ||
| Curb Weight | 3875kg | ||
| Gross Weight | 7100kg | ||
| Seats | 2+3 | ||
| Max Speed | 90km/h | ||
| Chassis | |||
| Chassis Model | BJ1073VEADA-C2 | ||
| Front/Rear Overhang | 1130/1580mm | ||
| Number of Leaf Springs | 4/6+7 | ||
| Number of Axles | 2 | ||
| Wheelbase | 3360mm | ||
| Axle Load | 2350/4750kg | ||
| Front Wheel Track | 1550mm | ||
| Rear Wheel Track | 1590mm | ||
| Approaching/Departuring Angle | 21/14° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 7.00R16LT 14PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| 4B2-115C50 | Anhui Quanchai Power Co., Ltd. | 85kW | 2545ml |
| ISF2.8s5129T | Beiqi Foton Cummins Engine Co., Ltd. | 96kW | 2780ml |
| 4J28TC3 | Beiqi Footn Motor Co., Ltd. | 81kW | 2771ml |
| CY4BK551 | Dongfeng Chaoyang Diesel Co., Ltd. | 75kW | 3707ml |
| YN33CRE1 | Kunming Yunnei Power Co., Ltd. | 85kW | 3298ml |
| D25TCIE1 | Kunming Yunnei Power Co., Ltd. | 105kW | 2499ml |
| YN27CRE1 | Kunming Yunnei Power Co., Ltd. | 70kW | 2672ml |
