| Basic Information |
| Usage |
Engineering Vehicle |
| Fuel Type |
Diesel |
| Emission Standard |
GB17691-2005 national Ⅴ emission standards, GB3847-2005 |
| Length |
9970,10320mm |
| Width |
2550mm |
| Height |
3990mm |
| Curb Weight |
14200kg |
| Gross Weight |
31000kg |
| Seats |
2 |
| Max Speed |
82km/h |
| Chassis |
| Chassis Model |
ZZ1313N306GE1 |
| Front/Rear Overhang |
1500/2270,1500/2620,1500/2245,1500/2595mm |
| Number of Leaf Springs |
11/11/10,3/3/4,3/3/5,11/11/4,11/11/5 |
| Number of Axles |
4 |
| Wheelbase |
1800+3025+1400,1800+3050+1350mm |
| Axle Load |
6500/7000/17500(two axles)kg |
| Front Wheel Track |
2035/2035mm |
| Rear Wheel Track |
1850/1850mm |
| Approaching/Departuring Angle |
14/14° |
| Tire |
| Number of Tires |
12 |
| Tire |
12R22.5,11.00R20 |
| Engine |
| Model |
MC07.31-50,MC07.34-50,MC07.34-52 |
| Power |
228,248,248kW |
| Brand |
China National Heavy Duty Truck Group Co., Ltd.;China National Heavy Duty Truck Group Co., Ltd.;China National Heavy Duty Truck Group Co., Ltd. |
| Displacement |
6870,6870,6870ml |
