| Basic Information | |||
| Usage | Engineering Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards | ||
| Length | 10150mm | ||
| Width | 2550mm | ||
| Height | 3990mm | ||
| Curb Weight | 14000kg | ||
| Gross Weight | 31000kg | ||
| Seats | 2 | ||
| Max Speed | 80km/h | ||
| Chassis | |||
| Chassis Model | BJ5319GJB-AD | ||
| Front/Rear Overhang | 1450/2500mm | ||
| Number of Leaf Springs | left 14 right 13/ left 14 right 13/12, left 14 right 13/ left 14 right 13/14,13/14/12,3/3/5,10/10/12,13/14/14,11/11/14,10/10/10 | ||
| Number of Axles | 4 | ||
| Wheelbase | 1800+3050+1350mm | ||
| Axle Load | 6500/6500/18000(two axles)kg | ||
| Front Wheel Track | 2010/2010mm | ||
| Rear Wheel Track | 1865/1865mm | ||
| Approaching/Departuring Angle | 12/14° | ||
| Tire | |||
| Number of Tires | 12 | ||
| Tire | 11.00R20 16PR,11.00R20 18PR,12.00R20 14PR,12.00R20 16PR,12.00R20 18PR,12R22.5 16PR,12R22.5 18PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| ISGe5-320 | Beijing Foton Cummins Engine Co., Ltd. | 235kW | 10500ml |
| ISGe5-340 | Beijing Foton Cummins Engine Co., Ltd. | 250kW | 10500ml |
