| Basic Information | |||
| Usage | Engineering Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 10400mm | ||
| Width | 2550mm | ||
| Height | 3990mm | ||
| Curb Weight | 14740kg | ||
| Gross Weight | 31000kg | ||
| Seats | 2,3 | ||
| Max Speed | 84km/h | ||
| Chassis | |||
| Chassis Model | CA5310GJBP66K2L1T4E5 | ||
| Front/Rear Overhang | 1470/2480,1500/2500mm | ||
| Number of Leaf Springs | 9/9/10,11/11/12,10/10/12,9/9/11 | ||
| Number of Axles | 4 | ||
| Wheelbase | 1900+3200+1350,1950+3100+1350,1950+2900+1350mm | ||
| Axle Load | 6500/6500/18000(two axles)kg | ||
| Front Wheel Track | 2020/2020,1950/1950mm | ||
| Rear Wheel Track | 1878/1878mm | ||
| Approaching/Departuring Angle | 15/18° | ||
| Tire | |||
| Number of Tires | 12 | ||
| Tire | 12R22.5,11.00R20,12.00R20 18PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| CA6DL3-37E5 | China FAW Group Co., Ltd. | 279kW | 8600ml |
