| Basic Information | |||
| Usage | Engineering Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 10100,10350mm | ||
| Width | 2500,2550mm | ||
| Height | 3995mm | ||
| Curb Weight | 16600kg | ||
| Gross Weight | 25000kg | ||
| Seats | 2,3 | ||
| Max Speed | 85km/h | ||
| Chassis | |||
| Chassis Model | BJ5253GJB-XL | ||
| Front/Rear Overhang | 1532/2918,1532/3168mm | ||
| Number of Leaf Springs | 9/12,10/12 | ||
| Number of Axles | 3 | ||
| Wheelbase | 4300+1350mm | ||
| Axle Load | 7000/18000(two axles)kg | ||
| Front Wheel Track | 2028,2080mm | ||
| Rear Wheel Track | 1880/1880mm | ||
| Approaching/Departuring Angle | 16/° | ||
| Tire | |||
| Number of Tires | 10 | ||
| Tire | 12.00R20 16PR,12.00-20 16PR,12.00-20 18PR,11.00R20 18PR,11.00-20 18PR,12R22.5 18PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| WP12.375E50 | Weichai Power Co., Ltd. | 276kW | 11596ml |
| WP10.336E53 | Weichai Power Co., Ltd. | 247kW | 9726ml |
