| Basic Information | |||
| Usage | Engineering Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 9160mm | ||
| Width | 2550mm | ||
| Height | 3920mm | ||
| Curb Weight | 14500kg | ||
| Gross Weight | 25000kg | ||
| Seats | 2,3 | ||
| Max Speed | 86km/h | ||
| Chassis | |||
| Chassis Model | SX3250MB4J | ||
| Front/Rear Overhang | 1485/2500mm | ||
| Number of Leaf Springs | 10/12 | ||
| Number of Axles | 3 | ||
| Wheelbase | 3975+1400,3775+1400mm | ||
| Axle Load | 7000/18000(two axles)kg | ||
| Front Wheel Track | 2011,2036mm | ||
| Rear Wheel Track | 1860/1860mm | ||
| Approaching/Departuring Angle | 18/° | ||
| Tire | |||
| Number of Tires | 10 | ||
| Tire | 11.00-20 18PR,12.00-20 18PR,11.00R20 18PR,12.00R20 16PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| WP10.336E55 | Weichai Power Co., Ltd. | 247kW | 9726ml |
| WP12.375E55 | Weichai Power Co., Ltd. | 276kW | 11596ml |
| WP7.300E55 | Weichai Power Co., Ltd. | 220kW | 7470ml |
