| Basic Information | |||
| Usage | Engineering Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards | ||
| Length | 9800mm | ||
| Width | 2550mm | ||
| Height | 3850mm | ||
| Curb Weight | 12000kg | ||
| Gross Weight | 31000kg | ||
| Seats | 2,3 | ||
| Max Speed | 89km/h | ||
| Chassis | |||
| Chassis Model | DFH1310B | ||
| Front/Rear Overhang | 1470/2130mm | ||
| Number of Leaf Springs | 3/3/3,3/3/4,3/3/10 | ||
| Number of Axles | 4 | ||
| Wheelbase | 1850+3000+1350mm | ||
| Axle Load | 6500/6500/18000(two axles)kg | ||
| Front Wheel Track | 1934/1934mm | ||
| Rear Wheel Track | 1860/1860,1880/1880mm | ||
| Approaching/Departuring Angle | 15/° | ||
| Tire | |||
| Number of Tires | 12 | ||
| Tire | 11R22.5 18PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| ISD300 50 | Dongfeng Cummins Engine Co., Ltd. | 221kW | 6700ml |
