| Basic Information |
| Usage |
Engineering Vehicle |
| Fuel Type |
Diesel |
| Emission Standard |
GB3847-2005,GB17691-2018 national Ⅵ emission standards |
| Length |
10500mm |
| Width |
2550mm |
| Height |
3990mm |
| Curb Weight |
14800kg |
| Gross Weight |
31000kg |
| Seats |
2 |
| Max Speed |
89km/h |
| Chassis |
| Chassis Model |
SX1319MB6F1 |
| Front/Rear Overhang |
1525/2775mm |
| Number of Leaf Springs |
3/3/5,14/14/12,10/10/10,10/10/12,3/3/4,2/2/4,5/5/5 |
| Number of Axles |
4 |
| Wheelbase |
1800+3000+1400,1800+3375+1400,1800+3175+1400,1950+2850+1400mm |
| Axle Load |
6500/6500/18000(two axles)kg |
| Front Wheel Track |
2011/2011,2036/2036,2070/2070mm |
| Rear Wheel Track |
1860/1860mm |
| Approaching/Departuring Angle |
16/14° |
| Tire |
| Number of Tires |
12 |
| Tire |
11.00R20 18PR,12R22.5 18PR |
| Engine |
| Model |
WP8.350E61,WP8.320E61,WP7.300E61,WP10H400E62,WP9H350E62,WP8.350E61A,L9NS6B360 |
| Power |
257,235,220,294,257,257,265kW |
| Brand |
Weichai Power Co., Ltd.;Weichai Power Co., Ltd.;Weichai Power Co., Ltd.;Weichai Power Co., Ltd.;Weichai Power Co., Ltd.;Weichai Power Co., Ltd.;Dongfeng Cummins Engine Co., Ltd. |
| Displacement |
7800,7800,7470,9500,8800,7800,8900ml |
