| Basic Information | |||
| Usage | Engineering Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 10250,9980mm | ||
| Width | 2550mm | ||
| Height | 3990mm | ||
| Curb Weight | 13780kg | ||
| Gross Weight | 31000kg | ||
| Seats | 2 | ||
| Max Speed | 80km/h | ||
| Chassis | |||
| Chassis Model | NXG3310D5NEMX | ||
| Front/Rear Overhang | 1485/2565,1400/2650,1485/2295,1400/2380mm | ||
| Number of Leaf Springs | 3/3/4,9/9/13,4/4/5 | ||
| Number of Axles | 4 | ||
| Wheelbase | 1950+2900+1350mm | ||
| Axle Load | 6500/6500/18000(two axles)kg | ||
| Front Wheel Track | 2060/2060,2040/2040,2000/2000mm | ||
| Rear Wheel Track | 1860/1860mm | ||
| Approaching/Departuring Angle | 23/13° | ||
| Tire | |||
| Number of Tires | 12 | ||
| Tire | 10.00R20 18PR,11.00R20 18PR,12R22.5 18PR,11R22.5 18PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| WP7.300E51 | Weichai Power Co., Ltd. | 220kW | 7470ml |
| WP10.350E53 | Weichai Power Co., Ltd. | 257kW | 9726ml |
| WP8.340E51 | Weichai Power Co., Ltd. | 250kW | 7800ml |
