| Basic Information | |||
| Usage | Engineering Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB3847-2005,GB17691-2018 national Ⅵ emission standards | ||
| Length | 10250mm | ||
| Width | 2550mm | ||
| Height | 3990mm | ||
| Curb Weight | 14100kg | ||
| Gross Weight | 31000kg | ||
| Seats | 2 | ||
| Max Speed | 89km/h | ||
| Chassis | |||
| Front/Rear Overhang | 1525/2525mm | ||
| Number of Leaf Springs | 3/3/5,14/14/12,10/10/10,10/10/12,3/3/4,2/2/4 | ||
| Number of Axles | 4 | ||
| Wheelbase | 1800+3000+1400mm | ||
| Axle Load | 6500/6500/18000(two axles)kg | ||
| Front Wheel Track | 2011/2011,2036/2036,2070/2070mm | ||
| Rear Wheel Track | 1860/1860mm | ||
| Approaching/Departuring Angle | 16/14° | ||
| Tire | |||
| Number of Tires | 12 | ||
| Tire | 11.00R20 18PR,12R22.5 18PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| WP8.320E61 | Weichai Power Co., Ltd. | 235kW | 7800ml |
| WP8.350E61 | Weichai Power Co., Ltd. | 257kW | 7800ml |
| WP7.300E61 | Weichai Power Co., Ltd. | 220kW | 7470ml |
| WP9H350E62 | Weichai Power Co., Ltd. | 257kW | 8800ml |
| WP10H400E62 | Weichai Power Co., Ltd. | 294kW | 9500ml |
