| Basic Information |
| Usage |
Engineering Vehicle |
| Fuel Type |
Diesel |
| Emission Standard |
GB17691-2005 national Ⅴ emission standards, GB3847-2005 |
| Length |
10300,9980mm |
| Width |
2550mm |
| Height |
3990mm |
| Curb Weight |
13720kg |
| Gross Weight |
31000kg |
| Seats |
2,3 |
| Max Speed |
80km/h |
| Chassis |
| Chassis Model |
SX5310GJBMB6 |
| Front/Rear Overhang |
1525/2575,1525/2255mm |
| Number of Leaf Springs |
3/3/5,3/3/-,10/10/12,10/10/10,left 14 right 13/left 14 right 13/12,4/4/5,2/2/4,3/3/4,14/14/12,5/5/5 |
| Number of Axles |
4 |
| Wheelbase |
1800+3000+1400,1800+3575+1400,1800+3775+1400,1800+3175+1400,1800+3375+1400mm |
| Axle Load |
6500/6500/18000(two axles)kg |
| Front Wheel Track |
2036/2036,2011/2011,2070/2070mm |
| Rear Wheel Track |
1860/1860mm |
| Approaching/Departuring Angle |
10/° |
| Tire |
| Number of Tires |
12 |
| Tire |
295/80R22.5,11.00R20,12.00R20 18PR,295/80R22.5 16PR,295/80R22.5 18PR,11.00R20 16PR,11.00R20 18PR,12R22.5 16PR,12R22.5 18PR,12.00R20 16PR |
| Engine |
| Model |
WP7.300E51,WP9H336E50,WP7.340E53,WP10.350E53,WP10H375E50,WP10.336E53,ISM11E5 345,WP10.336E55,WP8.340E51,WP10H400E50 |
| Power |
220,247,250,257,276,247,250,247,250,294kW |
| Brand |
Weichai Power Co., Ltd.;Weichai Power Co., Ltd.;Weichai Power Co., Ltd.;Weichai Power Co., Ltd.;Weichai Power Co., Ltd.;Weichai Power Co., Ltd.;Xi'an Cummins Engine Co., Ltd.;Weichai Power Co., Ltd.;Weichai Power Co., Ltd.;Weichai Power Co., Ltd. |
| Displacement |
7470,8800,7470,9726,9500,9726,10800,9726,7800,9500ml |
