| Basic Information |
| Usage |
Engineering Vehicle |
| Fuel Type |
Diesel |
| Emission Standard |
GB17691-2005 national Ⅴ emission standards, GB3847-2005 |
| Length |
10350,9980mm |
| Width |
2550mm |
| Height |
3990mm |
| Curb Weight |
13780kg |
| Gross Weight |
31000kg |
| Seats |
2 |
| Max Speed |
80km/h |
| Chassis |
| Chassis Model |
BJ5313GJB-AA |
| Front/Rear Overhang |
1532/2618,1532/2248mm |
| Number of Leaf Springs |
left 14 right 13/left 14 right 13/12,left 14 right 13/left 14 right 13/14,13/14/12,3/3/5,3/3/4,10/10/12 |
| Number of Axles |
4 |
| Wheelbase |
1800+3050+1350,2000+2850+1350mm |
| Axle Load |
6500/6500/18000(two axles)kg |
| Front Wheel Track |
2010/2010mm |
| Rear Wheel Track |
1860/1860mm |
| Approaching/Departuring Angle |
15/14° |
| Tire |
| Number of Tires |
12 |
| Tire |
12.00-20 14PR,12.00-20 16PR,12.00-20 18PR,12.00R20 14PR,12.00R20 16PR,12.00R20 18PR,11.00R20 16PR,11.00R20 18PR,11.00-20 16PR,11.00-20 18PR,12R22.5 18PR |
| Engine |
| Model |
ISGe5-320,ISGe5-340,WP9H310E50,WP9H336E50 |
| Power |
235,250,228,247kW |
| Brand |
Beijing Foton Cummins Engine Co., Ltd.;Beijing Foton Cummins Engine Co., Ltd.;Weichai Power Co., Ltd.; Weichai Power Co., Ltd. |
| Displacement |
10500,10500,8800,8800ml |
