| Basic Information | |||
| Usage | Engineering Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards | ||
| Length | 10100mm | ||
| Width | 2550mm | ||
| Height | 3990mm | ||
| Curb Weight | 13430kg | ||
| Gross Weight | 31000kg | ||
| Seats | 2 | ||
| Max Speed | 80km/h | ||
| Chassis | |||
| Chassis Model | CDW3313N3661E1BN | ||
| Front/Rear Overhang | 1460/2440mm | ||
| Number of Leaf Springs | 4/4/5,9/9/12,8/8/10,9/9/10,11/11/12 | ||
| Number of Axles | 4 | ||
| Wheelbase | 1800+3050+1350mm | ||
| Axle Load | 6500/6500/18000(two axles)kg | ||
| Front Wheel Track | 1965/1965,2020/2020,2070/2070mm | ||
| Rear Wheel Track | 1800/1800,1860/1860mm | ||
| Approaching/Departuring Angle | 17/14° | ||
| Tire | |||
| Number of Tires | 12 | ||
| Tire | 10.00R20 18PR,11.00R20 18PR,11R22.5 18PR,12R22.5 18PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| WP8.340E51 | Weichai Power Co., Ltd. | 250kW | 7800ml |
