| Basic Information | |||
| Usage | Engineering Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2018 national Ⅵ emission standards | ||
| Length | 10450mm | ||
| Width | 2550mm | ||
| Height | 3990mm | ||
| Curb Weight | 14800kg | ||
| Gross Weight | 31000kg | ||
| Seats | 2 | ||
| Max Speed | 80km/h | ||
| Chassis | |||
| Chassis Model | XGA3310D6NEX | ||
| Front/Rear Overhang | 1485/2765mm | ||
| Number of Leaf Springs | 3/3/4,9/9/13,3/3/13,4/4/6,3/3/5,9/9/10,9/9/12,10/10/10,10/10/12,10/10/13,3/3/10,3/3/12,4/4/5 | ||
| Number of Axles | 4 | ||
| Wheelbase | 1950+2900+1350mm | ||
| Axle Load | 6500/6500/18000(two axles)kg | ||
| Front Wheel Track | 2060/2060,2020/2020,2000/2000,2040/2040mm | ||
| Rear Wheel Track | 1860/1860,1880/1880mm | ||
| Approaching/Departuring Angle | 18/13° | ||
| Tire | |||
| Number of Tires | 12 | ||
| Tire | 11.00R20 18PR,12R22.5 18PR,12.00R20 18PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| WP8.350E61 | Weichai Power Co., Ltd. | 257kW | 7800ml |
