| Basic Information |
| Usage |
Engineering Vehicle |
| Fuel Type |
Diesel |
| Emission Standard |
GB3847-2005,GB17691-2018 national Ⅵ emission standards |
| Length |
10450mm |
| Width |
2550mm |
| Height |
3990mm |
| Curb Weight |
14800kg |
| Gross Weight |
31000kg |
| Seats |
2 |
| Max Speed |
80km/h |
| Chassis |
| Chassis Model |
CQ1317HL6Z |
| Front/Rear Overhang |
1435/2815mm |
| Number of Leaf Springs |
3/3/6,8/8/12,9/9/12,10/10/12,3/3/12 |
| Number of Axles |
4 |
| Wheelbase |
2000+2800+1400,2000+3000+1400,2000+4000+1400,2000+3200+1400,2150+4250+1400mm |
| Axle Load |
6500/6500/18000(two axles)kg |
| Front Wheel Track |
2020/2020,2040/2040,2060/2060mm |
| Rear Wheel Track |
1858/1858mm |
| Approaching/Departuring Angle |
16/14° |
| Tire |
| Number of Tires |
12 |
| Tire |
12R22.5 18PR,315/80R22.5 18PR,11.00R20 18PR,12.00R20 18PR,295/80R22.5 18PR,315/60R22.5 20PR |
| Engine |
| Model |
SC10E400Q6,SC10E330Q6,SC10E370Q6,SC10E300Q6,SC10E420Q6,F2CCE611G*M,F2CCE611H*M,F2CCE611J*M,F2CCE611K*M |
| Power |
294,243,272,221,309,287,263,243,215kW |
| Brand |
Shanghai Diesel Engine Co., Ltd.;Shanghai Diesel Engine Co., Ltd.;Shanghai Diesel Engine Co., Ltd.;Shanghai Diesel Engine Co., Ltd.;Shanghai Diesel Engine Co., Ltd.;Saic Fiat Powertrain Hongyan Co., Ltd.;Saic Fiat Powertrain Hongyan Co., Ltd.;Saic Fiat Powertrain Hongyan Co., Ltd.;Saic Fiat Powertrain Hongyan Co., Ltd. |
| Displacement |
10420,10420,10420,10420,10420,8709,8709,8709,8709ml |
