| Basic Information |
| Usage |
Engineering Vehicle |
| Fuel Type |
Diesel |
| Emission Standard |
GB3847-2005,GB17691-2018 national Ⅵ emission standards |
| Length |
10300mm |
| Width |
2550mm |
| Height |
3990mm |
| Curb Weight |
13430kg |
| Gross Weight |
31000kg |
| Seats |
2 |
| Max Speed |
80km/h |
| Chassis |
| Chassis Model |
BJ5319GJBY6GRL-01 |
| Front/Rear Overhang |
1460/2640mm |
| Number of Leaf Springs |
left 14 right 13/left 14 right 13/12,left 14 right 13/left 14 right 13/14,13/14/12,3/3/5,10/10/12,13/14/14,11/11/14,10/10/10,3/3/4 |
| Number of Axles |
4 |
| Wheelbase |
2100+2750+1350,2100+3100+1350mm |
| Axle Load |
6500/6500/18000(two axles)kg |
| Front Wheel Track |
2020/2020,2050/2050,2080/2080mm |
| Rear Wheel Track |
1830/1830,1865/1865,1880/1880mm |
| Approaching/Departuring Angle |
20/14° |
| Tire |
| Number of Tires |
12 |
| Tire |
11.00-20 18PR,11.00-20 16PR,11.00R20 18PR,11.00R20 16PR,12.00-20 18PR,12.00-20 16PR,12.00-20 14PR,12.00R20 18PR,12.00R20 16PR,12.00R20 14PR,12R22.5 18PR,12R22.5 16PR |
| Engine |
| Model |
X11NS6B360,X11NS6B400,X12NS6B360,X12NS6B380,WP8.350E61A |
| Power |
265,294,265,279,257kW |
| Brand |
Beijing Foton Cummins Engine Co., Ltd.;Beijing Foton Cummins Engine Co., Ltd.;Beijing Foton Cummins Engine Co., Ltd.;Beijing Foton Cummins Engine Co., Ltd.;Weichai Power Co., Ltd. |
| Displacement |
10500,10500,11800,11800,7800ml |
