| Basic Information | |||
| Usage | Engineering Vehicle | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 10100mm | ||
| Width | 2550mm | ||
| Height | 3995mm | ||
| Curb Weight | 15700kg | ||
| Gross Weight | 25000kg | ||
| Seats | 2 | ||
| Max Speed | 80km/h | ||
| Chassis | |||
| Chassis Model | CQ1256HTVG40-474 | ||
| Front/Rear Overhang | 1435/2865mm | ||
| Number of Leaf Springs | 3/4,3/6,3/12,9/12 | ||
| Number of Axles | 3 | ||
| Wheelbase | 4000+1400,4200+1400,4400+1400,4700+1400mm | ||
| Axle Load | 7000/18000(two axles)kg | ||
| Front Wheel Track | 2006,2020,2070mm | ||
| Rear Wheel Track | 1850/1850mm | ||
| Approaching/Departuring Angle | 19/° | ||
| Tire | |||
| Number of Tires | 10 | ||
| Tire | 11.00-20 18PR,11.00R20 18PR,12.00-20 18PR,12.00R20 16PR,12R22.5 18PR,315/80R22.5 18PR/315/80R22.5 16PR/315/80R22.5 16PR,295/80R22.5 18PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| F2CCE611A*L | Saic Fiat Powertrain Hongyan Co., Ltd. | 287kW | 8709ml |
| F2CCE611B*L | Saic Fiat Powertrain Hongyan Co., Ltd. | 257kW | 8709ml |
