| Basic Information | |||
| Usage | Engineering Vehicle | ||
| Fuel Type | Natural gas | ||
| Emission Standard | GB17691-2018 national Ⅵ emission standards | ||
| Length | 10300mm | ||
| Width | 2550mm | ||
| Height | 3990mm | ||
| Curb Weight | 14000kg | ||
| Gross Weight | 31000kg | ||
| Seats | 2 | ||
| Max Speed | 80km/h | ||
| Chassis | |||
| Chassis Model | XGA3310N6NEX | ||
| Front/Rear Overhang | 1485/2615mm | ||
| Number of Leaf Springs | 3/3/4,9/9/13,2/2/3,4/4/5,3/3/3,4/4/12,9/9/10,9/9/12 | ||
| Number of Axles | 4 | ||
| Wheelbase | 1950+2900+1350,1950+3300+1350mm | ||
| Axle Load | 6500/6500/18000(two axles)kg | ||
| Front Wheel Track | 2060/2060,2020/2020mm | ||
| Rear Wheel Track | 1860/1860mm | ||
| Approaching/Departuring Angle | 18/14° | ||
| Tire | |||
| Number of Tires | 12 | ||
| Tire | 10.00R20 18PR,11.00R20 18PR,12R22.5 18PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| WP10HNG350E60 | Weichai West Port New Energy Power Co., Ltd. | 257kW | 9500ml |
