| Basic Information |
| Usage |
Engineering Vehicle |
| Fuel Type |
Natural gas |
| Emission Standard |
GB17691-2018 national Ⅵ emission standards |
| Length |
10250mm |
| Width |
2550mm |
| Height |
3990mm |
| Curb Weight |
13370kg |
| Gross Weight |
31000kg |
| Seats |
2,3 |
| Max Speed |
89km/h |
| Chassis |
| Chassis Model |
DFV1318GP6NJ |
| Front/Rear Overhang |
1500/2450mm |
| Number of Leaf Springs |
3/3/4,9/9/10,9/9/13,10/10/13 |
| Number of Axles |
4 |
| Wheelbase |
1850+3100+1350,1850+3200+1350,1850+3300+1350,1850+3500+1350,1850+3800+1350,1850+4050+1350,1850+4250+1350,1850+4600+1350,1850+4800+1350,1850+3000+1350,1850+2700+1350,1850+2900+1350,1850+2850+1400,1850+3150+1400,1850+3250+1400,1850+3450+1400,1850+3750+1400,mm |
| Axle Load |
6500/6500/18000(two axles)kg |
| Front Wheel Track |
1940/1940,1960/1960,2010/2010,2040/2040mm |
| Rear Wheel Track |
1860/1860mm |
| Approaching/Departuring Angle |
20/14° |
| Tire |
| Number of Tires |
12 |
| Tire |
11.00R20 18PR,12.00R20 16PR,12R22.5 18PR,295/80R22.5 18PR,12.00R20 18PR |
| Engine |
| Model |
6K1343N-60,6K1346N-60,YCK11380N-60,YCK11340N-60,YCK11360N-60 |
| Power |
316,339,280,250,265kW |
| Brand |
Y&C Engine Co., Ltd.;Y&C Engine Co., Ltd.;Guangxi Yuchai Machinery Co., Ltd.;Guangxi Yuchai Machinery Co., Ltd.;Guangxi Yuchai Machinery Co., Ltd. |
| Displacement |
12939,12939,10980,10980,10980ml |
