| Basic Information | |||
| Usage | Semi-Trailer | ||
| Length | 11300,11520mm | ||
| Width | 2550mm | ||
| Height | 3800,3950mm | ||
| Curb Weight | 6500kg | ||
| Gross Weight | 40000kg | ||
| Chassis | |||
| Chassis Model | |||
| Front/Rear Overhang | -/1680,-/1900mm | ||
| Number of Leaf Springs | -/3/3/3,-/4/4/4,-/7/7/7,-/10/10/10,-/-/-/- | ||
| Number of Axles | 3 | ||
| Wheelbase | 5500+1310+1310mm | ||
| Axle Load | -/24000(three axles)kg | ||
| Front Wheel Track | -mm | ||
| Rear Wheel Track | 2040/2040/2040,2090/2090/2090mm | ||
| Approaching/Departuring Angle | -/17,-/15° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 425/65R22.5 20PR | ||
