| Basic Information | |||
| Usage | Fire Extinguishing Truck | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 8320mm | ||
| Width | 2500mm | ||
| Height | 3610mm | ||
| Curb Weight | 11475kg | ||
| Gross Weight | 16000kg | ||
| Seats | 3+4 | ||
| Max Speed | 90km/h | ||
| Chassis | |||
| Chassis Model | QL1180XMFRY | ||
| Front/Rear Overhang | 1335/2350mm | ||
| Number of Leaf Springs | 9/7+7 | ||
| Number of Axles | 2 | ||
| Wheelbase | 4500mm | ||
| Axle Load | 5000/11000kg | ||
| Front Wheel Track | 1960mm | ||
| Rear Wheel Track | 1855mm | ||
| Approaching/Departuring Angle | 15/12° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 295/80R22.5 16PR,11.00R20 16PR | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| 6HK1-TCL | Qingling Isuzu (Chongqing) Engine Co., Ltd. | 177kW | 7790ml |
