| Basic Information | |||
| Usage | Fire Extinguishing Truck | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 11420mm | ||
| Width | 2500mm | ||
| Height | 3330mm | ||
| Curb Weight | 16050kg | ||
| Gross Weight | 36200kg | ||
| Seats | 2 | ||
| Max Speed | 90km/h | ||
| Chassis | |||
| Chassis Model | Actros 4148E5 | ||
| Front/Rear Overhang | 1440/2630mm | ||
| Number of Leaf Springs | 3/3/3/3 | ||
| Number of Axles | 4 | ||
| Wheelbase | 1700+4300+1350mm | ||
| Axle Load | 6000/5810/12195/12195kg | ||
| Front Wheel Track | 2034/2034mm | ||
| Rear Wheel Track | 1804/1804mm | ||
| Approaching/Departuring Angle | 16/10° | ||
| Tire | |||
| Number of Tires | 12 | ||
| Tire | 315/70R22.5 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| OM501LA.V/6 | Daimler AG | 355kW | 11946ml |
