| Basic Information | |||
| Usage | Fire Extinguishing Truck | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 10740mm | ||
| Width | 2500mm | ||
| Height | 3860mm | ||
| Curb Weight | 20100kg | ||
| Gross Weight | 31800kg | ||
| Seats | 2 | ||
| Max Speed | 80km/h | ||
| Chassis | |||
| Chassis Model | CQ5346TXHTVG47-594 | ||
| Front/Rear Overhang | 1435/2905mm | ||
| Number of Leaf Springs | 9/12,3/4 | ||
| Number of Axles | 3 | ||
| Wheelbase | 4700+1400,5000+1400,5900+1400mm | ||
| Axle Load | 6500/12650/12650kg | ||
| Front Wheel Track | 2006,2020,2070mm | ||
| Rear Wheel Track | 1850/1850mm | ||
| Approaching/Departuring Angle | 19/10° | ||
| Tire | |||
| Number of Tires | 10 | ||
| Tire | 12.00-20,12.00R20,315/80R22.5 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| F2CCE611A*L | Saic Fiat Powertrain Hongyan Co., Ltd. | 287kW | 8709ml |
| F2CCE611B*L | Saic Fiat Powertrain Hongyan Co., Ltd. | 257kW | 8709ml |
| F2CCE611C*L | Saic Fiat Powertrain Hongyan Co., Ltd. | 235kW | 8709ml |
| F2CCE611D*L | Saic Fiat Powertrain Hongyan Co., Ltd. | 215kW | 8709ml |
| F3GCE611B*L | Saic Fiat Powertrain Hongyan Co., Ltd. | 318kW | 11120ml |
| F3GCE611C*L | Saic Fiat Powertrain Hongyan Co., Ltd. | 288kW | 11120ml |
