| Basic Information | |||
| Usage | Vehicle for Special Work | ||
| Fuel Type | Diesel | ||
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 | ||
| Length | 8995mm | ||
| Width | 2480mm | ||
| Height | 3850mm | ||
| Curb Weight | 11000kg | ||
| Gross Weight | 12450kg | ||
| Seats | 1 | ||
| Max Speed | 100km/h | ||
| Chassis | |||
| Chassis Model | KLQ6902KAE50 | ||
| Front/Rear Overhang | 1905/2790mm | ||
| Number of Leaf Springs | 8/11 | ||
| Number of Axles | 2 | ||
| Wheelbase | 4300mm | ||
| Axle Load | 3900/8550kg | ||
| Front Wheel Track | 2020,2050,2112mm | ||
| Rear Wheel Track | 1844,1864,1942mm | ||
| Approaching/Departuring Angle | 13/10° | ||
| Tire | |||
| Number of Tires | 6 | ||
| Tire | 10R22.5,275/70R22.5 | ||
| Engine | |||
| Model | Brand | Power | Displacement |
| YC6J220-50 | Guangxi Yuchai Machinery Co., Ltd. | 162kW | 6500ml |
| YC6J245-50 | Guangxi Yuchai Machinery Co., Ltd. | 180kW | 6500ml |
| WP6.245E50 | Weifang Weichai Deutz Engine Co., Ltd. | 180kW | 6750ml |
| YC6A270-50 | Guangxi Yuchai Machinery Co., Ltd. | 199kW | 7520ml |
| WP7.270E53 | Weichai Power Co., Ltd. | 199kW | 7470ml |
